Introduction of RCGX series CBN inserts

• RCGX series cubic boron nitride inserts are positioned with a 120° cone, so that the insert and the cutter body are tightly fixed together to complete the cutting of difficult-to-machine material workpieces. The service life is 5-10 times longer than that of carbide tools and ceramic tools. Greatly improve processing efficiency.

• SCBN Tools CBN Grade For RCGX as follows:

• The common models of RCGX are RCGX0605, RCGX0606, RCGX0907, RCGX1207, RCGX1510, RCGX1910, the largest can be RCGX2512.

  Standard cutting edges for RCGX inserts are S01020, S02020, S03025, S05020, S10025 and S20020 etc.




RCGX series cubic boron nitride tool application

• RCGX insert is efficiently used in the finishing of the slewing bearing raceway, which realizes the replacement of grinding by turning, and the efficiency is increased by more than 5 times compared with grinding.




• RCGX inserts are also commonly used in the processing of threaded roll threads, which can process high-hardness rolls, such as high-speed steel rolls, forged steel rolls, etc. It has excellent wear resistance, and the processing efficiency is greatly improved.
